| Model |
|
DS-7608NI-K2 |
DS-7616NI-K2 |
DS-7632NI-K2 |
| Video/
Audio input
|
IP video input |
8-ch |
16-ch |
32-ch |
| Incoming bandwidth |
80 Mbps |
160 Mbps |
256 Mbps |
| Outgoing bandwidth |
160 Mbps |
| Video/
Audio output
|
HDMI output
resolution
|
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA output
resolution
|
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Audio output |
1-ch, RCA (Linear, 1 KΩ) |
| Decoding |
Decoding format |
H.265/H.265+/H.264/H.264+/MPEG4 |
| Recording resolution |
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF
/2CIF/CIF/QCIF
|
| Synchronous playback |
8-ch |
16-ch |
16-ch |
| Capability |
2-ch @ 4K, or 8-ch @ 1080p |
| Network management |
Network protocols |
TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| Hard disk |
SATA |
2 SATA interfaces |
| Capacity |
Up to 6TB capacity for each HDD |
| External interface |
Two-way audio |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network interface |
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| USB interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm in/out |
4/1 |
| General |
Power supply |
12 VDC |
| Power |
≤ 40 W |
| Consumption
(without hard disk)
|
≤15 W |
| Working temperature |
-10 to +55ºC (14 to 131ºF ) |
| Working humidity |
10 to 90 % |
| Chassis |
385 mm chassis |
| Dimensions
(W × D × H)
|
385 × 315× 52 mm (15.2″ × 12.4″ × 2.0″) |
| Weight
(without hard disk)
|
≤ 1 kg (2.2 lb) |
