DS-2CD6425G0/F-XX – Dual-Lens DeepinView Separated Network Camera

• Camera
• Image Sensor1/2.8″ Progressive Scan CMOS
• Min. Illumination

  Color: 0.001 Lux @ (F1.2, AGC ON), 0.006 Lux @ (F2.5, AGC ON)

  B/W: 0.0007 Lux@(F1.2, AGC ON), 0.003 Lux@(F2.5, AGC ON)

• Shutter Speed

  Channel 1: 1/25 s to 1/100,000 s

  Channel 2: 1 s to 1/100,000 s

• Slow ShutterChannel 2: Yes
• Day &NightL10, L20, L30: Electronic
• Angle AdjustmentNo
• Digital Noise Reduction3D DNR
• WDR120 dB
• Auto-IrisNo

• Lens
• Aperture

  L10: F2.5

  L20: F 2.5

  L30: 2 mm: F 2.0; 2.8/4 mm: F 1.6

• FocusNo
• FOV

  L10: 3.7 mm, F 2.5, horizontal FOV 75° vertical FOV 41.5°, diagonal FOV 87°

  L20: 2.8 mm/3.7 mm

  2.8 mm: F 2.5, horizontal FOV 94°, vertical FOV 51.5°, diagonal FOV 109°

  3.7 mm: F 2.5, horizontal FOV 75°, vertical FOV 41.5°, diagonal FOV 87°

  L30: 2 mm/2.8 mm/4 mm

  2 mm: F 2.0, horizontal FOV 132.8°, vertical FOV 77.5°, diagonal FOV 153°

  2.8 mm: F 1.6, horizontal FOV 110.5°, vertical FOV 60°, diagonal FOV 130°

  4 mm: F 1.6, horizontal FOV 86°, vertical FOV 45°, diagonal FOV 102°

• Lens MountM12
• Focal Length

  L10: 3.7 mm

  L20: 2.8mm, 3.7 mm

  L30: 2 mm, 2.8 mm, 4 mm

• Audio
• Environment Noise FilteringYes
• Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz

• Smart Feature-Set
• Face Capture

  Channel 1: Yes

  Channel 2: No

• Behavior Analysis

  Channel 1: Line crossing detection, intrusion detection, region entrance, region exiting, unattended baggage, object removal

  Channel 2: No

• Region Of Interest

  Channel 1: 4 fixed regions for each stream, and dynamic face tracking

  Channel 2: No

• Exception Detection

  Channel 1: Scene change detection, defocus detection, audio exception detection

  Channel 2: No

• Face Detection

  Channel 1: Yes

  Channel 2: No

• Image
• Image EnhancementBLC, HLC, 3D DNR, Defog, EIS
• Image SettingRotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Target CroppingNo
• Day/Night SwitchDay/Night/Auto/Schedule/Triggered by Alarm in
• Picture OverlayLOGO picture can be overlaid on video with 128 × 128 24bit bmp format
• Max. Resolution1920 × 1080
• Main Stream

  50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)

  60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

• Sub Stream

  50Hz: 25fps (704 × 576, 640 × 480)

  60Hz: 30fps (704 × 480, 640 × 480)

• Network
• Network StorageMicro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
• ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• APIONVIF (PROFILE S, PROFILE G), ISAPI
• Simultaneous Live ViewUp to 20 channels
• User/Host

  Up to 32 users

  3 levels: Administrator, Operator and User

• ClientiVMS-4200, iVMS-4500, iVMS-5200, Hik-connect
• Web BrowserIE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
• Alarm TriggerMotion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
• General FunctionOne-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
• Firmware VersionV5.5.42

• Interface
• Communication Interface1 RJ45 10M/100M Ethernet port, RS485, built-in RS232
• Audio1 input (line in), 1 output (line out), mono sound
• Alarm2 inputs, 2 outputs (up to 12 VDC 30mA)
• Video OutputNo
• On-Board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB
• Reset ButtonYes

• Compression Standard
• H.264+Main stream support
• H.265+Main stream support
• H.264 TypeBaseline Profile/Main Profile/High Profile
• Video Compression

  Main stream: H.265/H.264

  Sub-stream: H.265/H.264/MJPEG

• H.265 TypeMain Profile
• Video Bitrate32 Kbps to 16 Mbps
• Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC
• Audio Bitrate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
• SVCH.264 and H.265 support

• General
• Power Supply

  12 VDC + PoE, 8-36 VDC, two-core terminal block

  PoE (802.3at, class 4)

• Power Consumption And Current

  12 VDC, 1.3 A, max. 15W, 8-36 VDC,

  PoE (802.3at,class 4): 42.5 V to 57 V, 0.4 A to 0.3 A, max. 16 W

• MaterialMetal
• DimensionsMain body: 135 × 107.8 ×30.4 mm (5.3″ × 4.3″ × 1.2″)

• Main body: approx. 450 g (1 lb.)

  With Package: 900 g (2 lb.)

• Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity ≤ 95% or less (non-condensing)
• Protection LevelL30: IP66 (2 mm: No)
